CO2 Laser marking machine 30W/50W, Laser printer marking machine
$4,199.00
| Technical Parameters |
| Laser type CO2 laser Carbon dioxide laser domestic/imported |
| Laser wavelength 10640nm |
| Output power 20W/30W/50W/100W |
| Beam quality M2 <1.2 |
| Pulse repetition frequency 10kHz~100kHz |
| Cooling method Air cooling |
| Processing area 110*110~300*300mm(customization supported) |
| Focusing range ≤+30mm |
| Marking speed ≤15000mm/s |
| Marking line width 0.1mm(depending on the material) |
| Marking depth 0.01-2mm |
| Characters can reach 0.05mm |
| Repeat accuracy ≤±0.1μm |
| Supported formats PLT、JPG、BMP、PNG、TIP、PCX、TGA、DXF、ICOetc. |
| Operating environment 18~28℃ temperature |
| Operating voltage 110V-220V 50Hz/60Hz |
| Machine weight 100KG |
| Dimensions (LxWxH):80×65×145cm |
| Machine power |
